Synthetic Oil
Synthetic Oil
Synthetic oil is a lubricant made from artificial chemical compounds, and is used to replace refined hydrocarbon-based lubricants. It is used in high-performance engines and in extreme conditions, such as high temperatures or pressures.
○ Some of the characteristics of synthetic oil are:
○ Mechanical and chemical properties: They are superior to those of mineral oils.
○ Fluidity: Its high fluidity implies lower viscosities, which reduces engine stress and oil consumption.
○ Resistance to corrosion, oxidation and wear: It is capable of resisting up to five times more than a mineral oil.
○ Protection in extreme temperatures: It can protect the engine in temperatures ranging from -40° to 400°
We present the following variants:
⦁ Neopentyl Polyol Ester Type Synthetic Base Oil for Internal Combustion Engine Oils
⦁ Poly Alpha Olefin Synthetic Base Oil
⦁ Polyol Ester Base Oil
⦁ Alkylated Naphtalene Base Oil
⦁ High Temperature Chain Lubricant Oil
⦁ Trimethylolpropane Trioleate
⦁ Polymethacrylate Hydraulic Oil Viscosity Index Improver
⦁ Polyol Complex Ester Base Oil
⦁ Synthetic Polyol Ester Type Oil. Refrigerant Oil
⦁ Synthetic Polyalkylene Glycol Type Oil. Refrigerant Oil
Neopentyl Polyol Ester Type Synthetic Base Oil for Internal Combustion Engine Oils
| Product | HH-2820 | HH-2823 | Test Method |
|---|---|---|---|
| Appearance | Colorless or Light Yellow Liquid | Colorless or Light Yellow Liquid | Visual |
| Density (20℃) kg/m³ | 0.94 | 0.94 | ASTM D1298 |
| Kinematic Viscosity, 100°C mm2/s | 4.468 | 4.62 | ASTM D445 |
| Kinematic Viscosity, 40°C mm2/s | 20.01 | 21.52 | ASTM D445 |
| Viscosity Index（VI） | 140 min | 135 | ASTM D2270 |
| Flash Point（COC）°c | 255 max | 258 max | ASTM D92 |
| Pour Point，0C | -52 max | -45 max | ASTM D97 |
| Acid Number, KOHmg/g | 0.0 1max | 0.03 max | ASTM D974 |
| Iodine Value, g/100g | 0.2 | 0.2 | ASTM D4607 |
| Hydroxyl Value, mgKOH/g | 0.5 max | 0.5 max | ASTM E1899 |
| Cold Cranking Simulator Viscosity, CCS @-30, mPa.s | 2189 | 2268 | ASTM D5293 |
| NOACK KOH number 250°C/1hr,%W/W | 3.16 | 3.96 | ASTM D5800 |
Engine Oil Formulation
| Formulation： | SN 0W-20 | SN 5W-20 | SN 5W-30 | SN 10W-30 | SN 10W-40 |
|---|---|---|---|---|---|
| HH-2820 Base Oil | 20 | 20 | 20 | 15 | 15 |
| YUbase 4 Hydrogenated Base Oil | 58.1 | 25 | 15 | ― | ― |
| YUbase 6 Hydrogenated base oil | 6 | 39.1 | 48.1 | 68.1 | 41.2 |
| YUbase 8 Hydrogenated Base Oil | ― | ― | ― | ― | 25 |
| Functional Additive Package | 10.6 | 10.6 | 10.6 | 10.6 | 10.6 |
| VII Base Oil | 5 | 5 | 6 | 6 | 8 |
| PMA-Type PPD (Polymethacrylate Pour-Point Depressant Additive) | 0.3 | 0.3 | 0.3 | 0.3 | 0.2 |
| amount | 100 | 100 | 100 | 100 | 100 |
| KV,100℃,mm2/s | 8.801 | 8.892 | 10.63 | 10.68 | 14.82 |
| Pour Point,℃ | -41 | -38 | -38 | -33 | -33 |
| Cold Cranking Simulator Viscosity, CCS @-30, mPa.s | 5800 (-35℃) | 5100 ( -30°C ) | 5200 ( -30°C ) | 4200 ( -25°C ) | 5950 ( -25°C ) |
| HTHS Viscosity (High Temperature High Shear), 150°C, cP | 2.8 | 2.89 | 3.15 | 3.2 | 4 |
| Volatilization Loss,250℃, 1h | 8.26 | 7.93 | 7.74 | 7.69 | 6.4 |
Poly Alpha Olefin Synthetic Base Oil
Poly α olefin base oil belongs to synthetic base oil, which is different from mineral base oil extracted from petroleum by physical distillation. Synthetic base oil is the one composed of Macromolecule refined by ethylene and propylene dispersed by gas or natural gas from crude oils after the polymerization and catalysis and other complex chemical reactions .
| Product | PAO2 | PA04 | PAO6 | PAO8 | PAO10 | PAO20 | PAO40 | PAO100 | PAO V600 | PAO V1000 | Test |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Density (20℃) kg/m³ | 0.797 | 0.82 | 0.827 | 0.833 | 0.832 | 0.843 | 0.845 | 0.853 | 0.8495 | 0.849 | ASTM D1298 |
| Kinematic Viscosity (100℃) mm²/s | 1.7 | 3.9 | 5.9 | 7.8 | 9.9 | 20 | 40 | 100.8 | 604 | 1010 | ASTM D445 |
| Kinematic Viscosity (40℃) mm²/s | 5.1 | 16.9 | 30.5 | 46 | 64.4 | 168 | 386 | 1258 | 7348 | 11700 | ASTM D445 |
| Viscosity Index | ― | 123 | 135 | 138 | 139 | 138 | 254 | 170 | 270 | 310 | ASTM D2270 |
| Flash Point ℃ | 160 | 219 | 238 | 258 | 260 | 268 | 285 | 295 | 300 | >300 | ASTM D92 |
| Pour Point ℃ | -73 | -73 | -68 | -57 | -52 | -45 | -39 | -30 | -21 | -18 | ASTM D97 |
| Color Scale | <0.5 | <0.5 | 0.5 | <0.5 | <0.5 | <0.5 | <0.5 | <0.5 | <0.5 | <0.5 | ASTM D1500 |
| Acid Number, KOHmg/g | ― | ― | ― | ― | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | ASTM D974 |
| Water Content, mg/kg | ― | ― | ― | ― | 30 | 30 | 30 | 30 | 30 | ― | ASTM D95 |
| Noack Volatility Loss, wt% | ― | 11 | 6 | 2.8 | 3.2 | 2.7 | 0.7 | 0.6 | 0.8 | <0.1 | ASTM D5800 |
Polyol Ester Base Oil
Polyol Ester Base Oil is refined by molecular distillation after the reaction between neo-polyhydric alcohol and saturated straight/branched-chain fatty acids. Some HH's refrigerating machine oils formulated with these POE ester base oils have been successfully applied to refrigeration compressors in main engine plants. It has excellent mutual solubility and compatibility with new environment-friendly refrigerants. POE Polyol Ester Base Oils have excellent hydrolytic stability.
| Product | RL32 | RL46 | RL68 | RL100 | RL120 | RL150 | RL170 | RL220 | RL320 | Test |
|---|---|---|---|---|---|---|---|---|---|---|
| ISO Viscosity Grade | 32 | 46 | 68 | 100 | 120 | 150 | 170 | 220 | 320 | ISO VG System |
| Kinematic Viscosity (40℃) mm²/s | 32.5 | 46.7 | 68.2 | 99.8 | 120.4 | 150.5 | 171.1 | 226.5 | 328.5 | ASTM D445 |
| Color Scale | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | ASTM D1500 |
| Density (20℃) kg/m³ | 983 | 984 | 986 | 1020 | 1017 | 1013 | 1010 | 1004 | 1006 | ASTM D1298 |
| Visosity Index | 112 | 106 | 105 | 115 | 112 | 102 | 108 | 104 | 128 | ASTM D2270 |
| Flash Point ℃ | 235 | 242 | 250 | 265 | 268 | 272 | 280 | 287 | 290 | ASTM D92 |
| Pour Point ℃ | -60 | -50 | -45 | -42 | -39 | -33 | -33 | -33 | -30 | ASTM D97 |
| Acid Number, KOHmg/g | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 | ASTM D974 |
| Extreme Pressure Performance | 3500 | 3650 | 3820 | 4020 | 4035 | 4100 | 4150 | 4200 | 4250 | ASTM D3233 |
Alkylated Naphtalene Base Oil
Alkylated Naphthalene Group V API Base Oil. The superior performance of Alkylated Naphthalene base oil is primarily due to its structure, which contains an electron naphthalene ring. This gives it exceptional thermal oxidation stability and excellent hydrolysis stability. As global prices of lithium salts, used as thickeners, continue to rise and supply becomes increasingly uncertain, the addition of Alkylated Naphthalene (ANs) to lithium grease is becoming even more crucial.
| Product | AN5 | AN15 | AN23 | AN30 | Test Method |
|---|---|---|---|---|---|
| Apparance | Light yellow, bright & clear | Light yellow, bright & clear | Light yellow, bright & clear | Light yellow, bright & clear | Visual |
| Density (20℃) kg/m³ | 0.907 | 0.885 | 0.875 | 0.872 | ASTM D1298 |
| Kinematic Viscosity (100℃) mm²/s | 4.52 | 15.1 | 20.5 | 29.85 | ASTM D445 |
| Kinematic Viscosity (40℃) mm²/s | 26.5 | 140 | 206 | 301 | ASTM D445 |
| Viscosity Index | 68 | 109 | 116 | 135 | ASTM D2270 |
| Flash Point ℃ | 220 | 260 | 288 | 320 | ASTM D92 |
| Pour Point ℃ | -50 | -40 | -39 | -20 | ASTM D97 |
| Acid Number, KOHmg/g | 0.01 | 0.01 | 0.01 | 0.01 | ASTM D974 |
| Aniline Point, ℃ | 32 | 96 | 110 | 125 | ASTM D611 |
| Noack Volatility Loss, wt% | 18.5 | 2.2 | 1.3 | <1.0 | ASTM D5800 |
| Cold Cranking Simulator Viscosity, CCS @-30, mPa.s | 6700 | ― | ― | ― | ASTM D5293 |
| Color Scale | L 1.5 | ― | ― | ― | ASTM D1500 |
| Demulsibility (40/40/0), min | 1’22’’ | ― | ― | ― | ASTM D1401 |
| Thermogravimetric Analysis, 90 ℃ | ― | 468.4 | 473 | ― | ASTM D3850 |
Polyol Complex Ester Base Oil
Polyol Complex Ester Base Oil
High-viscosity complex ester base oil with excellent hydrolytic stability and anti-shear performance. It is also an efficient viscosity index improver for mineral and synthetic oils. It is recommended for thickening various lubricants and improving the lubrication performances of raw material, and can be used as the reinforcing additive for thiophosphorous extreme pressure additives.
Product Features
1. High oil film strength, excellent abrasion protection;
2. Excellent oxidation stability and thermal stability;
3. Chlorine-free EP technology, synergistic with thiophosphorus EP additive;
4. Good shear stability;
5. Good combustion cleanliness;
6. Low volatility;
7. High viscosity index;
8. Biodegradable;
9. Suitable in the formulations of pure oils and soluble oils.
| Product | HH-2000A | HH-2000B | Test Method |
|---|---|---|---|
| Kinematic Viscosity (40℃) mm²/s | 26.5 | 140 | ASTM D445 |
| Kinematic Viscosity (100℃) mm²/s | 4.52 | 15.1 | ASTM D445 |
| Viscosity Index | 68 | 109 | ASTM D2270 |
| Pour Point ℃ | -50 | -40 | ASTM D97 |
| Flash Point ℃ | 220 | 260 | ASTM D92 |
| Acid Number, KOHmg/g | 0.01 | 0.01 | ASTM D974 |
Polymethacrylate Hydraulic Oil Viscosity Index Improver
Polymethacrylate Hydraulic Oil Viscosity Index Improver
Hydraulic oil is a fluid that has several functions. It serves as an energy transfer or power transmission medium, lubricant, and sealant. Also, it is a fluid that cools the equipment and carries contaminants away.
| Product | 6300V | 6500V | 6100V | 826P | Test Method |
|---|---|---|---|---|---|
| Apparance | Colorless or light yellow thick liquid | Colorless or light yellow thick liquid | Colorless or light yellow thick liquid | Colorless or light yellow thick liquid | Visual |
| Kinematic Viscosity (100℃) mm²/s | 1354 | 395 | 3000 | 550 | ASTM D445 |
| Color Scale | 0.5 | 0.5 | ― | 0.5 | ASTM D1500 |
| Density (20℃) kg/m³ | 920 | 920 | ― | 920 | ASTM D1298 |
| Flash Point ℃ | 180 | 160 | 170 | 180 | ASTM D92 |
| Shear Stability Index (SSI) | 33.9(KRL 20h ) | KRL 20h 9.66 | ― | ― | ASTM D7109 |
| Shear Stability Index (SSI) | 7.3 (Diesel nozzle 250 cycles) | ― | ― | ― | ASTM D6278 |
| Shear Stability Index (SSI) | 4.4 (Diesel nozzle 40 cycles) | ― | ― | ― | ASTM D6278 |
| Thickening Ability, 100℃mm2/s | ― | ― | 15-20 | ― | ASTM D1500 |
Trimethylolpropane Trioleate | TMPTO | Cas No. 57675-44-2
TMPTO is derived from the fully monounsaturated oleic acid. This ester is widely used for industrial applications, such as hydraulic fluids, two-stroke engine oils and metalworking oils.
| Product | G-HFDU-32 | G-HFDU-46 | G-HFDU-68 | Test Method |
|---|---|---|---|---|
| Apparance | Transparent yellow liquid | Transparent yellow liquid | Transparent yellow liquid | Visual |
| Kinematic Viscosity (40℃) mm²/s | 31.62 | 45.72 | 65.08 | ASTM D445 |
| Kinematic Viscosity (100℃) mm²/s | 7.25 | 9.479 | 12.22 | ASTM D445 |
| Viscosity Index | 205 | 198 | 189 | ASTM 2161 |
| Flash Point ℃ | 300 | 300 | 300 | ASTM D92 |
| Ignition Point,℃ | 300 | 300 | 300 | ASTM D92 |
| Pour Point ℃ | -25 | -51 | -48 | ASTM D97 |
| Acid Number, KOHmg/g | 0.15 | 0.08 | 0.12 | ASTM D974 |
| Density (20℃) kg/m³ | 915.5 | 913.6 | 917.8 | ASTM D1298 |
| Water, % | Trace | Trace | Trace | ASTM D95 |
| Mechanical Impurities, % | 0.001 | 0.001 | 0.001 | ASTM D5800 |
| Iodine value, g/100g | 86 | 86 | 88 | ASTM D4607 |
| Saponification Value, mgKOH/g | 178 | 179 | 180 | ASTM D5558 |
| Hydroxyl Value, mgKOH/g | 5 | 5 | 6 | ASTM E1899 |
| Air Releasing Value,50℃,min | 1.2 | 1.1 | 1.5 | ASTM D3427 |
| Foaming Characteristics,mL/mL, @ 24 ℃ | 10/0 | 10/0 | 10/0 | ASTM D892 |
| Foaming Characteristics,mL/mL, After 24 ℃ | 10/0 | 10/0 | 10/0 | ASTM D892 |
| Foaming Characteristics,mL/mL, @ 93 ℃ | 10/0 | 10/0 | 10/0 | ASTM D892 |
| Demulsibility (40/40/0), min | 1’ | 1’ | 1’ | ASTM D1401 |
High Temperature Chain Transmission Oil
High Temperature Chain Transmission Lubricant Oil: Synthetic ester base oil designed specifically for high-temperature chain lubrication. This oil provides excellent lubricity, outstanding thermal oxidation stability, and superior adhesion properties. These attributes ensure smooth operation between chains and ratchets, preventing machine shutdowns, reducing maintenance frequency, improving energy efficiency, and avoiding issues such as poor oil-water separation, emulsification, chain deformation, and fracture during operation.
| Product | 28150 | 28220 | 28320 | 28800 | Test |
|---|---|---|---|---|---|
| Density (20℃) kg/m³ | 0.97 | 0.967 | 0.975 | 0.988 | ASTM D1298 |
| Kinematic Viscosity (100℃) mm²/s | 17.94 | 19.09 | 24.48 | 44.12 | ASTM D445 |
| Kinematic Viscosity (40℃) mm²/s | 165 | 237.1 | 311.5 | 827.9 | ASTM D445 |
| Viscosity Index | 120 | 91 | 112 | 95 | ASTM D2270 |
| Flash Point ℃ | 318 | 310 | 308 | 304 | ASTM D92 |
| Pour Point ℃ | -42 | -39 | -27 | -15 | ASTM D97 |
| Noack Volatility Loss, wt% | 0.77 | 0.64 | 0.45 | 0.66 | ASTM D5800 |
Synthetic Polyol Ester (POE) Type Oil. Refrigerant Oil
Polyol Ester Oil (POE) Type Refrigeration Oil
This series is high-performance fully synthetic refrigeration lubricants specially for lubricating refrigeration compressors, which are formulated with patent product POE and special lubricant additives, providing excellent lubricity, antiwear performances and stable chemical, thermal and hydrolytic stabilities.
Applications
HFCs,HCFCs,HFOs
Reciprocating, screw, rotary, centrifugal, scroll compressors.
| Product | RL32 | RL46 | RL68 | RL100 | RL120 | RL150 | RL170 | RL220 | RL320 | Test Method |
|---|---|---|---|---|---|---|---|---|---|---|
| ISO Viscosity Grade | 32 | 46 | 68 | 100 | 120 | 150 | 170 | 220 | 320 | ISO 3448 |
| Kinematic Viscosity, 40°C mm2/s | 32.5 | 46.7 | 68.2 | 99.8 | 120.4 | 150.5 | 171.1 | 226.5 | 328.5 | ASTM D445 |
| Color Scale | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | ASTM D1500 |
| Density,20°C,kg/m3 | 983 | 984 | 986 | 1020 | 1017 | 1013 | 1010 | 1004 | 1006 | ASTM D1298 |
| Viscosity Index (VI） | 112 | 106 | 105 | 115 | 112 | 102 | 108 | 104 | 128 | ASTM D2270 |
| Flash Point, °C | 235 | 242 | 250 | 265 | 268 | 272 | 280 | 287 | 290 | ASTM D92 |
| Pour Point, °C | -60 | -50 | -45 | -42 | -39 | -33 | -33 | -33 | -30 | ASTM D97 |
| Acid Number, KOHmg/g | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 | ASTM D974 |
| Extreme Pressure Performance Failure Load | 3500 | 3650 | 3820 | 4020 | 4035 | 4100 | 4150 | 4200 | 4250 | ASTM D3233 |
Technical Feature & Performance Advantage
| Outstanding Performance | Advantages |
|---|---|
| Excellent High Temperature Stability | Providing the evaporator cleanliness, reducing the unplanned downtime and maintenance costs |
| Relation Between Definite Miscibility and HFCs P-V-T | Ensuring operation efficiency of refrigeration system and oil return |
| Excellent Antiwear Performance | Reducing the compressor abrasion and maintenance costs |
| High Viscosity index, No Wax | Excellent low-temperature fluidity, no waxy sediment, improving the evaporator efficiency |
| Many Choices for Viscosities | Meeting the viscosity requirements of various equipment and applications |
| Environment Friendly | Meeting the standard requirements of REACH and RoHS |
Synthetic Polyalkylene Glycol (PAG) Type Oil. Refrigerant Oil
Polyalkylene Glycol Synthetic PAG Oil. Refrigerant Oil
This series are synthetic PAG refrigeration lubricant specially for automotive, commercial, industrial refrigeration and air conditioning compressors, withstand dilution by hydrocarbon chemicals and other compressed gases, particularly prominent in immersion screw compressors. These products have thermal stability, low ash content, high viscosity index, shear stability and excellent lubricity.
This product is especially suitable for propane (R290), propylene (R1270) and other hydrocarbon gas compressors.The product is used in screw compressors with unique advantages of resistance to carbonization chemicals and compressed gas dilution.
Applications
⦁ HFCs, HFOs, CO2
⦁ Methane, ethane, ethylene, propane, propylene, butane, butene, butadiene and chemical gases such as ammonia and vinyl chloride monomers
⦁ Lubricating iquefied petroleum gas, hydrocarbon chemicals and liquefied natural gas compressors
⦁ Reciprocating, screw, rotary, centrifugal, scroll compressors
| Product | PAG46 | PAG 68 | PAG 100 | PAG 150 | Test Method |
|---|---|---|---|---|---|
| ISO Viscosity Grade | 46 | 68 | 100 | 150 | ISO 3448 |
| Kinematic Viscosity, 40°C mm2/s | 44.5 | 68.1 | 102 | 148 | ASTM D445 |
| Color Scale | 0.5 | 0.5 | 0.5 | 1.5 | ASTM D1500 |
| Density,20°C,kg/m3 | 986 | 993 | 1014 | 1020 | ASTM D1298 |
| Viscosity Index (VI） | 192 | 197 | 215 | 220 | ASTM D2270 |
| Flash Point, °C | 192 | 196 | 226 | 256 | ASTM D92 |
| Pour Point, °C | -52 | -48 | -45 | -42 | ASTM D97 |
| Acid Number, KOHmg/g | 0.02 | 0.02 | 0.02 | 0.02 | ASTM D974 |
| Extreme Pressure Performance Failure Load | 4250 | 4450 | 4600 | 4650 | ASTM D3233 |
Technical Feature & Performance Advantage
| Outstanding Performance | Advantages |
|---|---|
| Excellent High Temperature Stability | Excellent chemical stability and oxidation resistance, can run for a long time |
| Improve the Efficient Use of Oil Products | Increase the efficiency |
| Compatibility | Good compatibility with common materials used in refrigeration system |
| Wide Selection of Viscosity | Meet the viscosity requirements of various equipment and applications |
| Excellent Bearing Lubrication | Stable lubricating film at high temperature |
Biodegradable Polyol Ester Synthetic Base Oil
Biodegradable Polyol Ester (POE) Synthetic Base Oil
Biodegradable Polyol Ester POE Synthetic Base Oil, has excellent low temperature performance, high breakdown voltage , fire-resistance performance and good biodegradability.
| Product Code / Ester-Tyoe Oils | Specification | Usage |
|---|---|---|
| HH-1820 | Diester/Ester-type Synthetic Base Oil | High temperature greases/Industrial gear oil/Aviation lubricant/Engine Oil |
| HH-1866 | polyol ester POE Ester Base Oil | Use for Transformer Oil |
| HH-2000 | Polyol Complex Ester Base Oil | Industrial lubricants |
| HH-2820/HH-2823 | Synthetic Polyol Ester Base Oil | Ester-type synthetic Base Oil specially used for internal combustion engine oils |
| HH-320 | Ester Base Oil | Use for High Temperature Chain Oils |
| HH-40 | Polyester High-viscosity Ester-based Poly Alpha Olefin, PAO | Many kinds of lubricants |
| POE: 32/46/68/100/150/170/220/320/260 | Synthetic Polyol Ester Base Oil | Used as Base oil for Refrigerant Oil |
| TMPTO: 32#/46#/68# | Trimethylolpropane Trioleate, TMPTO | Synthetic Ester Base Oil for Biodegradable Difficult-flammble Hydraulic Fluid(HFDU) |
Macrofotographic View of Synthetic Oil
